DIN 7504K
DIN 7504-K + ARVUL
DIN-7504-K screw mounted with a vulcanised EPDM-steel washer. It is self-drilling, has a hexagonal head and incorporates a stamped washer. Its drill-type tip allows materials such as sheet metal to be fixed without the need for prior drilling. The vulcanised washer ensures watertight joints in façades or roofs. It is made of zinc-plated steel.
Body material
Select
Diameter
Select
Length
Select
View all sizes
| Code | Description | Length (mm) | Diameter | Surf. protect | UOM | No. pcs | Stock | ||
|---|---|---|---|---|---|---|---|---|---|
| ABE144219 | Self-drilling screw with EPDM DIN7504K Zn 4,2x19 P14, footprint: 7 | 19 | 4,2 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE144225 | Self-drilling screw with EPDM DIN7504K Zn 4,2x25 P14, footprint: 7 | 25 | 4,2 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE144816 | Self-drilling screw with EPDM DIN7504K Zn 4,8x16 P14, footprint: 8 | 16 | 4,8 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE144819 | Self-drilling screw with EPDM DIN7504K Zn 4,8x19 P14, footprint: 8 | 19 | 4,8 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE144825 | Self-drilling screw with EPDM DIN7504K Zn 4,8x25 P14, footprint: 8 | 25 | 4,8 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE144832 | Self-drilling screw with EPDM DIN7504K Zn 4,8x32 P14, footprint: 8 | 32 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE144838 | Self-drilling screw with EPDM DIN7504K Zn 4,8x38 P14, footprint: 8 | 38 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE145522 | Self-drilling screw with EPDM DIN7504K Zn 5,5x22 P14, footprint: 8 | 22 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE145532 | Self-drilling screw with EPDM DIN7504K Zn 5,5x32 P14, footprint: 8 | 32 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE164219 | Self-drilling screw with EPDM DIN7504K Zn 4,2x19 P16, footprint: 7 | 19 | 4,2 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE164816 | Self-drilling screw with EPDM DIN7504K Zn 4,8x16 P16, footprint: 8 | 16 | 4,8 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE164819 | Self-drilling screw with EPDM DIN7504K Zn 4,8x19 P16, footprint: 8 | 19 | 4,8 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE164825 | Self-drilling screw with EPDM DIN7504K Zn 4,8x25 P16, footprint: 8 | 25 | 4,8 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE164832 | Self-drilling screw with EPDM DIN7504K Zn 4,8x32 P16, footprint: 8 | 32 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE164838 | Self-drilling screw with EPDM DIN7504K Zn 4,8x38 P16, footprint: 8 | 38 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE165519 | Self-drilling screw with EPDM DIN7504K Zn 5,5x19 P16, footprint: 8 | 19 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE165522 | Self-drilling screw with EPDM DIN7504K Zn 5,5x22 P16, footprint: 8 | 22 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE165525 | Self-drilling screw with EPDM DIN7504K Zn 5,5x25 P16, footprint: 8 | 25 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE165532 | Self-drilling screw with EPDM DIN7504K Zn 5,5x32 P16, footprint: 8 | 32 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE165538 | Self-drilling screw with EPDM DIN7504K Zn 5,5x38 P16, footprint: 8 | 38 | 5,5 | Zn | 1/C | 1000 | Sign up or log in to view availability and prices. | ||
| ABE165550 | Self-drilling screw with EPDM DIN7504K Zn 5,5x50 P16, footprint: 8 | 50 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE165563 | Self-drilling screw with EPDM DIN7504K Zn 5,5x63 P16, footprint: 8 | 63 | 5,5 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE165575 | Self-drilling screw with EPDM DIN7504K Zn 5,5x75 P16, footprint: 8 | 75 | 5,5 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE166319 | Self-drilling screw with EPDM DIN7504K Zn 6,3x19 P16, footprint: 10 | 19 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE166325 | Self-drilling screw with EPDM DIN7504K Zn 6,3x25 P16, footprint: 10 | 25 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE166332 | Self-drilling screw with EPDM DIN7504K Zn 6,3x32 P16, footprint: 10 | 32 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE166338 | Self-drilling screw with EPDM DIN7504K Zn 6,3x38 P16, footprint: 10 | 38 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE166350 | Self-drilling screw with EPDM DIN7504K Zn 6,3x50 P16, footprint: 10 | 50 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE166363 | Self-drilling screw with EPDM DIN7504K Zn 6,3x63 P16, footprint: 10 | 63 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE166375 | Self-drilling screw with EPDM DIN7504K Zn 6,3x75 P16, footprint: 10 | 75 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE166380 | Self-drilling screw with EPDM DIN7504K Zn 6,3x80 P16, footprint: 10 | 80 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE166390 | Self-drilling screw with EPDM DIN7504K Zn 6,3x90 P16, footprint: 10 | 90 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE166310 | Self-drilling screw with EPDM DIN7504K Zn 6,3x100 P16, footprint: 10 | 100 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE166311 | Self-drilling screw with EPDM DIN7504K Zn 6,3x110 P16, footprint: 10 | 110 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE166312 | Self-drilling screw with EPDM DIN7504K Zn 6,3x120 P16, footprint: 10 | 120 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE166313 | Self-drilling screw with EPDM DIN7504K Zn 6,3x130 P16, footprint: 10 | 130 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE166314 | Self-drilling screw with EPDM DIN7504K Zn 6,3x140 P16, footprint: 10 | 140 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE184819 | Self-drilling screw with EPDM DIN7504K Zn 4,8x19 P18, footprint: 8 | 19 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE184825 | Self-drilling screw with EPDM DIN7504K Zn 4,8x25 P18, footprint: 8 | 25 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE184838 | Self-drilling screw with EPDM DIN7504K Zn 4,8x38 P18, footprint: 8 | 38 | 4,8 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE185522 | Self-drilling screw with EPDM DIN7504K Zn 5,5x22 P18, footprint: 8 | 22 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE185525 | Self-drilling screw with EPDM DIN7504K Zn 5,5x25 P18, footprint: 8 | 25 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE185532 | Self-drilling screw with EPDM DIN7504K Zn 5,5x32 P18, footprint: 8 | 32 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE185538 | Self-drilling screw with EPDM DIN7504K Zn 5,5x38 P18, footprint: 8 | 38 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE185550 | Self-drilling screw with EPDM DIN7504K Zn 5,5x50 P18, footprint: 8 | 50 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE185563 | Self-drilling screw with EPDM DIN7504K Zn 5,5x63 P18, footprint: 8 | 63 | 5,5 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE186319 | Self-drilling screw with EPDM DIN7504K Zn 6,3x19 P18, footprint: 10 | 19 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE186325 | Self-drilling screw with EPDM DIN7504K Zn 6,3x25 P18, footprint: 10 | 25 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE186332 | Self-drilling screw with EPDM DIN7504K Zn 6,3x32 P18, footprint: 10 | 32 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE186338 | Self-drilling screw with EPDM DIN7504K Zn 6,3x38 P18, footprint: 10 | 38 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE186350 | Self-drilling screw with EPDM DIN7504K Zn 6,3x50 P18, footprint: 10 | 50 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE186363 | Self-drilling screw with EPDM DIN7504K Zn 6,3x63 P18, footprint: 10 | 63 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE186375 | Self-drilling screw with EPDM DIN7504K Zn 6,3x75 P18, footprint: 10 | 75 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE186380 | Self-drilling screw with EPDM DIN7504K Zn 6,3x80 P18, footprint: 10 | 80 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE186390 | Self-drilling screw with EPDM DIN7504K Zn 6,3x90 P18, footprint: 10 | 90 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE186310 | Self-drilling screw with EPDM DIN7504K Zn 6,3x100 P18, footprint: 10 | 100 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE186311 | Self-drilling screw with EPDM DIN7504K Zn 6,3x110 P18, footprint: 10 | 110 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE186312 | Self-drilling screw with EPDM DIN7504K Zn 6,3x120 P18, footprint: 10 | 120 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE186313 | Self-drilling screw with EPDM DIN7504K Zn 6,3x130 P18, footprint: 10 | 130 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE186314 | Self-drilling screw with EPDM DIN7504K Zn 6,3x140 P18, footprint: 10 | 140 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE255522 | Self-drilling screw with EPDM DIN7504K Zn 5,5x22 P25, footprint: 8 | 22 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE255525 | Self-drilling screw with EPDM DIN7504K Zn 5,5x25 P25, footprint: 8 | 25 | 5,5 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE256325 | Self-drilling screw with EPDM DIN7504K Zn 6,3x25 P25, footprint: 10 | 25 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE256332 | Self-drilling screw with EPDM DIN7504K Zn 6,3x32 P25, footprint: 10 | 32 | 6,3 | Zn | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| ABE256338 | Self-drilling screw with EPDM DIN7504K Zn 6,3x38 P25, footprint: 10 | 38 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE256350 | Self-drilling screw with EPDM DIN7504K Zn 6,3x50 P25, footprint: 10 | 50 | 6,3 | Zn | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| ABE256363 | Self-drilling screw with EPDM DIN7504K Zn 6,3x63 P25, footprint: 10 | 63 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256380 | Self-drilling screw with EPDM DIN7504K Zn 6,3x80 P25, footprint: 10 | 80 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256390 | Self-drilling screw with EPDM DIN7504K Zn 6,3x90 P25, footprint: 10 | 90 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256310 | Self-drilling screw with EPDM DIN7504K Zn 6,3x100 P25, footprint: 10 | 100 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256311 | Self-drilling screw with EPDM DIN7504K Zn 6,3x110 P25, footprint: 10 | 110 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256312 | Self-drilling screw with EPDM DIN7504K Zn 6,3x120 P25, footprint: 10 | 120 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256313 | Self-drilling screw with EPDM DIN7504K Zn 6,3x130 P25, footprint: 10 | 130 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. | ||
| ABE256314 | Self-drilling screw with EPDM DIN7504K Zn 6,3x140 P25, footprint: 10 | 140 | 6,3 | Zn | 1/C | 100 | Sign up or log in to view availability and prices. |
