Screw with drill tip, extra-flat rivet head and PH drive. Can be used in aluminium carpentry work or for assembling sheet metal. Its reduced head makes it particularly useful in joints where there are moving parts. It is self-tapping and self-drilling, so no pre-drilling is required. Made of zinc-plated steel.
Body material
Select
Diameter
Select
Length
Select
View all sizes
| Code | Description | Length (mm) | Diameter | Surf. protect | Max. thickness | UOM | No. pcs | Stock | ||
|---|---|---|---|---|---|---|---|---|---|---|
| RSZ3509 | Screw RS Zn 3,5x9, footprint: PH2 | 9 | 3,5 | Zn | 2,8 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ3513 | Screw RS Zn 3,5x13, footprint: PH2 | 13 | 3,5 | Zn | 6,2 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ3516 | Screw RS Zn 3,5x16, footprint: PH2 | 16 | 3,5 | Zn | 9,2 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ4213 | Screw RS Zn 4,2x13, footprint: PH2 | 13 | 4,2 | Zn | 4,3 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ4216 | Screw RS Zn 4,2x16, footprint: PH2 | 16 | 4,2 | Zn | 7,3 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ4219 | Screw RS Zn 4,2x19, footprint: PH2 | 19 | 4,2 | Zn | 10,3 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ4225 | Screw RS Zn 4,2x25, footprint: PH2 | 25 | 4,2 | Zn | 16,3 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSZ4232 | Screw RS Zn 4,2x32, footprint: PH2 | 32 | 4,2 | Zn | 23 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSZ4813 | Screw RS Zn 4,8x13, footprint: PH2 | 13 | 4,8 | Zn | 3,7 | 1/C | 500 | Sign up or log in to view availability and prices. | ||
| RSZ4816 | Screw RS Zn 4,8x16, footprint: PH2 | 16 | 4,8 | Zn | 5,5 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSZ4819 | Screw RS Zn 4,8x19, footprint: PH2 | 19 | 4,8 | Zn | 8,7 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSZ4825 | Screw RS Zn 4,8x25, footprint: PH2 | 25 | 4,8 | Zn | 14,7 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSZ4832 | Screw RS Zn 4,8x32, footprint: PH2 | 32 | 4,8 | Zn | 21,5 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSZ4838 | Screw RS Zn 4,8x38, footprint: PH2 | 38 | 4,8 | Zn | 27,5 | 1/C | 250 | Sign up or log in to view availability and prices. | ||
| RSA23509 | Screw RS A2 3,5x9,5, footprint: PH2 | 9,5 | 3,5 | 2,8 | 1/C | 500 | Sign up or log in to view availability and prices. | |||
| RSA24213 | Screw RS A2 4,2x13, footprint: PH2 | 13 | 4,2 | 7,3 | 1/C | 500 | Sign up or log in to view availability and prices. | |||
| RSA24216 | Screw RS A2 4,2x16, footprint: PH2 | 16 | 4,2 | 10,3 | 1/C | 500 | Sign up or log in to view availability and prices. | |||
| RSA24219 | Screw RS A2 4,2x19, footprint: PH2 | 19 | 4,2 | 16,3 | 1/C | 500 | Sign up or log in to view availability and prices. | |||
| RSA24816 | Screw RS A2 4,8x16, footprint: PH2 | 16 | 4,8 | 5,5 | 1/C | 250 | Sign up or log in to view availability and prices. | |||
| RSA24819 | Screw RS A2 4,8x19, footprint: PH2 | 19 | 4,8 | 8,7 | 1/C | 250 | Sign up or log in to view availability and prices. | |||
| RSA24825 | Screw RS A2 4,8x25, footprint: PH2 | 25 | 4,8 | 14,7 | 1/C | 250 | Sign up or log in to view availability and prices. |
